Moving Head Light Series

(SL-857-III) 575W Moving Head Spot Light
		Demo

Technical parameter

Voltage: AC110-240V/50-60Hz
Lamp: HMI575 discharge bulb
Power: 800W
Control Signal: DMX512
Control Channel: 12CH
Size: 510×450×580mm
N.W: 25kg
G.W: 28kg
7 colors, achieving high speed double way rainbow and
scrolling effect pattern internal rotating function.
Speed adjustment, clockwise and anticlockwise.
7 changeable patterns,
(including one glass pattern, 6 metal pattens and 1 white).
Mechanical linear dimming and 1-10 times/s strobe effect.
Horizontal direction 450°scanning,smooth scanning action
and accurate orientation of vertical 270°scanning,
3 prism effect, prism rotating.
Automatic focusing function.
DMX512 international digital display.
Compatible with DMX512internatrinal digital signal.
4 convection cooling fan, optimize internal air way design,
heat elimination rapidly.
According to various standard, IP20,
cable meet CE 20/22 standard.
